Air Shower

Product Description

Air Shower:-

The term air shower can refer to the specialized antechamber which is passed through before entering a clean room in order to blow off excess dust particles from clean room personnel before they enter, to minimize contamination. HEPA filters are generally used to decontaminate a room by filtering out particles greater than 0.3 micrometres in size.

This kind of local purifying equipment is located between clean room and unclean room. They are designed to blow air in different directions. Single-side shower, double-side shower, three-side shower and top shower. Spraying wind speed usually goes above 25 m/s through stainless steel nozzles.

Application

• Air Shower is an airborne pollutants barrier between clean room and the worker's gowning area and prevents accidental contamination due to the unwanted or improper opening of the doors.


• Air Shower Room can effectively remove the surface lint and particulates on the workers and their garments and completely drives them down to the breeze air circulating filtration system.


• They are available in a very wide variety of sizes and shapes, such as using a combination of straight, right or left angle, and U shapes, to provide a cleaning system to meet your specific application requirements.

Features

• Main body construction: heavy gauge Steel Plate with powder coating, and with stainless steel floor to minimize particle generation.


• Mechanical or electrical interlock : help prevent premature or mistaken opening of the pressure-sealed doors.


• An Emergency Stop push button: will override the operating cycle to release the door locks immediately.


• A power failure safety function: the door locks will open automatically, while power is fail accidentally, to protect workers from dangers.


• Interior fluorescent lamp and flush windows: for best visibility and safety.


• All units come standard with Programmable microprocessor control, touch panel, and timer w/LED Display.


• With Auto, Stop, Manual, Emergency Stop function keys.


• W/ Running, or Air Shower Clean Mode indicators fitted on FRT & RR door.


• An optional timer, which deactivates interlock system 5 seconds after air shower clean mode finished, is available.


• Audio system is available for an option.


• Custom sizes are possible.
