Mini-Pleat HEPA Filter
Product Details:
X
Product Description
Mini-Pleat HEPA Filter:-
| Mini-pleat hepa filters are available in the following standard sizes | |||||||||||
| 1220 x 605 x 80 mm | |||||||||||
| 915 x 605 x 80 mm | |||||||||||
| 605 x 605 x 80 mm | |||||||||||
| Non-Standard sizes can also be manufactured as per specific customer requirements | |||||||||||
| The filter can be assembled with / without flanges | |||||||||||
| Available in casing thickness from 1 to 1.5 mm in variants of Mild steel/Galvanised steel/Aluminium/Stainless steel | |||||||||||
| Powder coating is the standard surface finishing offered | |||||||||||
| Filtration media is all glass, microfibre, fire retardant hepa filtration media manufactured by M/s.Lydall Inc, USA | |||||||||||
| Aluminium separators made from 0.04 mm thick aluminium foil in the case of deep pleat version. | |||||||||||
| High impact poly styrene seperators in the case of mini pleat version | |||||||||||
| Synthetic soft rubber gasket with dovetail joints. | |||||||||||
| Epoxy & Silicon Sealants | |||||||||||
| Initial pressure drop of 18 mm WC for deep pleat filters and 14 mm WC for mini pleat filters | |||||||||||
| Suitability to class 100 clean rooms and work stations as per FED:STD:209E | |||||||||||
| Efficiency 99.98% down to 0.3 microns. Suitable for H13 class as per EN779 | |||||||||||
| All filters are particle counted and DOP leak tested | |||||||||||
| Filter construction as per recommendations of IES-RP-001 | |||||||||||
| Each filter is accompanied by a test certificate | |||||||||||
| APPLICATIONS | |||||||||||
| |||||||||||
